Description
- 1024×600 high resolution
- Resistive touch control
- Compatible and Direct-connect with any revision of Raspberry Pi (except the Pi 1 model B or Pi Zero, which requires an HDMI cable)
- Drivers provided (works with your own Raspbian/Ubuntu directly)
- Also works as a computer monitor, in this case, touch panel is unavailable and HDMI cable is required
- HDMI interface for displaying, no I/Os required (however, the touch panel still needs I/Os)
- Backlight can be turned off to lower power consumption
- PIN NO - 1, 17: 3.3V (Power positive (3.3V power input))
- PIN NO - 2, 4: 5V (Power positive (5V power input))
- PIN NO - 3, 5, 7, 8, 10, 11, 12, 13, 15, 16, 18, 24: NC (NC)
- PIN NO - 6, 9, 14, 20, 25: GND (Ground)
- PIN NO - 19: TP_SI (SPI data input of Touch Panel)
- PIN NO - 21: TP_SO (SPI data output of Touch Panel)
- PIN NO - 22: TP_IRQ (Touch Panel interrupt, low level while the Touch Panel detects touching)
- PIN NO - 23: TP_SCK (SPI clock of Touch Panel)
- PIN NO - 26: TP_CS (Touch Panel chip selection, low active)
