Waveshare Core405R STM32F4 Core Board

WaveshareSKU: RB-Wav-1165
Manufacturer #: Part No.: Core405R
Price  :
£18.46

Tax included Shipping calculated at checkout.

On Demand See due date

This is an On Demand item and is not normally stocked. We will order it for you along with our next purchase from the supplier.

* Delays depend on the order frequency from each supplier and the approximate arrival date is indicated in the due date. Returns are not accepted on On Demand and Clearance Items except when they are found defective, in which case the product may be repaired or replaced at RobotShop's discretion.

Return
Policy
Return
Policy
Details View Details
Warranty
Terms
Warranty
Terms
View Details
Need
Help?
Need
Help?
Ask experts Ask Our Experts
£250+ Free
Shipping
Free Shipping Over £250*
View Details View Details

Description

  • Waveshare Core405R STM32F4 Core Board
  • Integrates essential components for STM32F4 development
  • Supports JTAG/SWD programming and debugging
  • Features versatile power supply options and boot selection
  • Offers extensive MCU communication interfaces
  • Provides easy access to all I/O ports via pin headers

The Waveshare Core405R STM32F4 Core Board is a development platform designed for the STM32F405RGT6 microcontroller, facilitating application development within the STM32F family. It integrates essential components such as a clock circuit and USB control circuit, with all I/O ports accessible via pin headers. The board supports JTAG/SWD programming and debugging interfaces, allowing for seamless integration into application boards. It features a power supply switch and boot mode selection, enhancing its versatility for various development needs.

  • 1x Waveshare Core405R STM32F4 Core Board
  • 1x USB Type A to Mini-B Cable
  • Weight: 0.095 kg

Website

  • Core405R, STM32F4 Core Board - Core405R Wiki
    • STM32F405RGT6: High-performance STM32 MCU
    • Core: Cortex-M4 32-bit RISC
    • Operating Frequency: 168MHz, 210 DMIPS/1.25 DMIPS/MHz
    • Operating Voltage: 1.8V-3.6V
    • Package: LQFP64
    • Memories: 1MB Flash, 192+4kB SRAM
    • Communication Interfaces: 3 x SPI, 4 x USART, 2 x UART, 2 x I2S, 3 x I2C, 1 x SDIO, 2 x CAN
    • USB 2.0 HS/FS device/host/OTG controller with dedicated DMA, on-chip full-speed PHY
    • USB HS ULPI (external PHY required)
    • AD & DA Converters: 3 x AD (12-bit, 1μs, shares 16 channels); 2 x DA (12-bit)
    • Debugging/Programming: Supports JTAG/SWD interfaces, supports IAP
    • AMS1117-3.3V Voltage Regulator
    • MIC2075-2: Onboard USB power management device
    • Power Supply Switch: Powered from 5Vin or USB connection
    • Boot Mode Selection: For configuring BOOT0 pin
    • Power Indicator
    • VBUS LED
    • Reset Button
    • 8M Crystal
    • 32.768K Crystal: For internal RTC with calibration
    • JTAG/SWD Interface: For debugging/programming
    • USB Connector: For establishing USB communication between PC and the STM32 development board
    • MCU Pins Expander: VCC, GND, and all I/O pins accessible on expansion connectors
    • 5Vin Pinheader: 5V power supply required when using USB HOST/OTG
    • USB Jumper: Short the jumper when using USB, open to disconnect from related I/O port
    • VBAT Selection Jumper: Short to use system power supply, open to connect VBAT to external power, such as a battery
